Giant SKU: 210000169881

Giant Trance X 2

$2,700.00 $3,700.00 Save $1,000

Shipping calculated at checkout

Size: XL

Only 1 in stock!

Giant Trance X 2 Trail Bike — 27.5" Wheels • Flip-Chip Geometry

Float through rock gardens, hit the jumps, and find the faster line. Quick-handling 27.5" wheels and adjustable frame geometry make this a lively trail bike. Choose a steeper or slacker head tube angle and a 20 mm or 30 mm bottom-bracket drop with the flip chip. The ALUXX SL aluminum frame runs updated Maestro rear suspension with 145 mm of smooth, active travel; a trunnion-mount shock and Advanced Forged Composite rocker keep traction and control high. Up front, a 160 mm fork boosts confidence.

Key Features

  • 27.5" wheels for quick, agile handling
  • Flip-chip geometry: steeper/slacker HTA & 20/30 mm BB drop options
  • ALUXX SL aluminum frame, Maestro suspension (145 mm rear travel)
  • Trunnion-mount shock & Advanced Forged Composite rocker arm
  • 160 mm suspension fork for aggressive terrain

Geometry

Values shown as “Setting A | Setting B”.

Metric Small Medium Large X-Large
Seat Tube Length (mm) 420 430 465 496
Seat Tube Angle 77.2° | 78.0° 76.3° | 77.0° 76.3° | 77.0° 76.3° | 77.0°
Top Tube Length (mm) 562 | 560 595 | 593 622 | 620 649 | 647
Head Tube Length (mm) 95 105 115 125
Head Tube Angle 63.7° | 64.5° 63.8° | 64.5° 63.8° | 64.5° 63.8° | 64.5°
Fork Rake (mm) 37 37 37 37
Trail (mm) 138 | 132 138 | 132 138 | 132 138 | 132
Wheelbase (mm) 1179 | 1177 1203 | 1202 1233 | 1231 1262 | 1260
Chainstay Length (mm) 433 | 430 433 | 430 433 | 430 433 | 430
BB Drop (mm) 30 | 20 30 | 20 30 | 20 30 | 20
Stack (mm) 596 | 590 605 | 599 614 | 608 623 | 617
Reach (mm) 427 | 435 447 | 455 472 | 480 497 | 505
Standover (mm) 709 | 718 714 | 723 740 | 750 762 | 772
Handlebar Width (mm) 800 800 800 800
Stem Length (mm) 40 40 50 50
Crank Length (mm) 165 170 170 170
Wheel Size 27.5" 27.5" 27.5" 27.5"

Specifications

Frame ALUXX SL-grade aluminum front & rear triangles; 145 mm Maestro suspension; flip chip; 12×148 mm thru-axle
Fork Fox 36 Rhythm, GRIP damper, 37 mm offset, 160 mm travel, 15×110 Kabolt, custom tuned for Giant
Rear Shock Fox Float DPS Performance, 185/55, custom tuned for Giant
Rims Giant AM 27.5, alloy
Hubs Alloy, sealed bearing
Spokes Sapim
Tires Front: Maxxis Assegai 27.5×2.6, 3C MaxxTerra, EXO, TR  |  Rear: Maxxis Minion DHR II 27.5×2.6, 3C MaxxTerra, EXO, TR, tubeless
Bottom Bracket SRAM DUB, press-fit
Crankset Truvativ Descendent 6k Eagle, 32T
Shifters SRAM NX Eagle, 1×12
Rear Derailleur SRAM NX Eagle
Cassette SRAM NX Eagle, 11–50
Chain SRAM GX Eagle
Brakes Shimano Deore BR-MT520 hydraulic
Rotors Shimano RT-66
Brake Levers Shimano Deore BL-MT501
Handlebar Giant Contact TR35, 800×35 mm, 20 mm rise
Grips Giant Tactal Pro Single
Stem Giant Contact SL 35
Seatpost TranzX travel-adjustable dropper, remote
Saddle Giant Romero
Pedals Sold separately
Accessories & Extras Tubeless prepared; 2.6" max tire size; 34T max chainring size

* Specifications are subject to change without notice.
